Fluke Networks LIQ-KIT-IE Industrial Ethernet Cable and Network Tester Kit

Product Description

The LinkIQ Cable+Network Tester is the testing solution to verify cable performance up to 10 Gb/s and solve network connectivity problems. LinkIQ validates cable performance using frequency-based measurements and provides distance to fault information along with a wire map of the cable under test. The LinkIQ also performs nearest switch diagnostics to identify key network issues and validate switch configuration eliminating the need of using another device. Additional features include Analog and Digital Toning, Port Blink, 802.1x authentication, Remote Office Locators, and the ability to manage results via LinkWare PC.

Sku: FLU-LIQ-KIT-IE
On Back-Order
$5,123.11 CAD

The LinkIQ™ is capable of measuring lengths up to 1000 feet (305 m) and provides distance to faults such as opens, shorts, and unterminated cable.

The included MS-IE Remote Adapter allows to identify mis-wired and split pairs on RJ45, M12X, M12D, and M8D terminated cables.

The LinkIQ™ supports EtherNet/IP, PROFINET, EtherCAT and other Industrial Ethernet and qualifies the cabling bandwidth from 10BASE-T to 10GBASE-T (10 Mb/s up to 10 Gb/s) and also provides nearest switch diagnostics including advertised data rate, switch name and port number and VLAN information, plus PoE testing and load test up to Class 8 (90W).

Includes LinkIQ™ Main Unit, Remote ID #1-7, IntelliTone(TM) Pro 200 Probe, RJ45-RJ45 patch cord (M-F), RJ45-RJ45 patch cord (M-F), Quick Reference Guide,AC charger, RJ45/11 universal coupler, RJ45/M12X patch cord, RJ45/M12D patch cord, RJ45/M8D patch cord, RJ45/11 Modular Adapter, Hanging strap with Remote ID holder, and duffle bag carry case.

Active Network Diagnostics
Diagnostic Protocols Link layer discovery protocol (LLDP)
Cisco discovery protocol (CDP)
Fast link pulses (FLP)
Nearest Device Diagnostics (If available through Diagnostic Protocols) Switch name
Port number
VLAN ame
Advertised data rates
Advertised duplex
Power Over Ethernet Compatibility IEEE 802.3af/at (SW v 1.0)
Hardware negotiation with signature resistance
Software negotiation with LLDP/CDP
Power Over Ethernet Diagnostics Advertised power class (1 to 4), SW v 1.0
Advertised available power
Powered pairs
Diagnostics for both single and dual signatures
Power Over Ethernet Measurements Loaded voltage (V), Loaded power (W)
Port Blink Blink the light of the connected port
Cable Test Specifications
Test Port Shielded 8-pin modular jack accepts 8-pin modular (RJ45) plugs
Commissioning Autotests 10GBASE-T, 5GBASE-T, 2.5GBASE-T, 1000BASE-T, 100BASE-TX, 10BASE-T, Wire map only
Test Speed: 6 seconds for lengths <229' (70 m)
Cable Types Balanced twisted-pair cabling
Unshielded twisted-pair
Screened twisted-pair
2-pair and/or 4-pair
Wire Map-Only Tests Document wire map
Length of each pair
Diagnose split pairs
User selectable T568A or T568B
User selectable crossover settings (straight through, half-crossover, full-crossover)
Test speed: 1 second for lengths <393' (120 m)
Length (Maximum) 1000' (305 m)
Nominal Velocity of Propagation (NVP) User settable
Tone Generator Generates digital tones compatible with Fluke Networks IntelliTone probe
Generates analog tones compatible with general analog probes
Remote ID Locators Use remote ID terminations to identify up to 7 unique ports or office outlets
General Specifications
Display 800 x 480 color capacitive multi-touch
Temperature Operating: 32 to 113°F (0 to 45°C)
Storage: -4 to 122°F (-20 to 50°C)
Operating Relative Humidity 0 to 90%, 32 to 95°F (0 to 35°C)
0 to 70%, 95 to 113°F (35 to 45°C)
Operating Altitude 13,123' (4000 m)
10,498' (3200 m) with AC adapter
Vibration Random, 2 g, 5 to 500 Hz
Drop 39" (1 m) drop, 6 sides
Battery Type: Lithium-ion, 3.6 V, 6400 mAh
Life: 8 hours typical
Charge time: 4.5 hours
Charging temperature range: 32 to 104°F (0 to 40°C)
Power Adapter Input: 100 to 240 V AC ±10%, 50/60 Hz
Output: 15 V DC, 2 A maximum
Class II
Host Interface USB type C
Dimensions 8.5 x 4.5" (21.59 x 11.43 cm)
Weight 1.6 lbs (624 g)


  • Fluke Networks LIQ-KIT-IE
  • LinkIQ Main Unit
  • Remote ID #1-7
  • IntelliTone(TM) Pro 200 Probe
  • RJ45-RJ45 patch cord (M-F)
  • Quick Reference Guide
  • AC charger
  • RJ45/11 universal coupler
  • RJ45/M12X patch cord
  • RJ45/M12D patch cord
  • RJ45/M8D patch cord
  • RJ45/11 Modular Adapter
  • Hanging strap with Remote ID holder
  • Duffle bag carry case



Fluke Networks LIQ-100-IE

  • LinkIQ™ Main Unit
  • Remote ID #1
  • RJ45-RJ45 patch cord (M-F)
  • Quick Reference Guide
  • AC charger
  • RJ45/11 universal coupler
  • RJ45/M12X patch cord
  • RJ45/M12D patch cord
  • RJ45/M8D patch cord
  • RJ45/11 Modular Adapter
  • Hanging strap with Remote ID holder
  • Duffle bag carry case
